TK2000 VHF Radio



Featured Features

  • Frequency Range: 440-470 MHz
  • 16 channels
  • 4 watts output power
  • Internal VOX function with 10 levels
  • QT / DQT signaling
  • Supplied with KRA-27M Antenna, KNB-63L Li-Ion Battery and KSC 35SE Quick Charger
  • Supplied with KRA-27M antenna, KNB-63L Li-Ion battery and KSC-35SE quick charger
  • Note - it does not include any encryption function, being ideal for use on networks where encryption is prohibited




Política de seguridad (editar con el módulo Información de seguridad y confianza para el cliente)



Política de envío (editar con el módulo Información de seguridad y confianza para el cliente)



Política de devolución (editar con el módulo Información de seguridad y confianza para el cliente)

<! - from KASC cache 02/08/2021: 12:42:09 -> <! - ProductHelper.renderFeaturesFast ->

Featured Features

Frequency Range: 136-174 MHz
16 channels
5 watts output power
Internal VOX function with 10 levels
QT / DQT signaling
Supplied with KRA-27M Antenna, KNB-63L Li-Ion Battery and KSC 35SE Quick Charger
Supplied with KRA-27M antenna, KNB-63L Li-Ion battery and KSC-35SE quick charger
Note - it does not include any encryption function, being ideal for use on networks where encryption is prohibited

Supplied accessories

Antenna Yes, KRA-27M
Battery Yes, KNB-63L
Belt clip Yes
Loader Yes, KSC-35SE
Instruction Manual Yes, English, Spanish, German, French, Dutch, Italian, Portuguese, Turkish and Greek
Fixing screw Yes


Applicable standards

R & amp; TTE: Yes, EN 300 086, 300 219, 301 489
EN60065, 60950-1, 60215 Yes
Factory and location quality certification ISO 9001. Manufactured in Shanghai
For use in the EU Yes
IP54 Yes
Measurement - EIA Standards Yes
MIL-STD 810 C / D / E / F / G Yes

Technical Specifications

Frequency range 440 - 470 MHz
Number of channels 16
Channel frequency spread 30 MHz
Channel Spacing - Analog - Wide / Medium / Narrow 25 kHz / 20 kHz / 12.5 kHz
Antenna impedance - 50 Ohm Yes
Battery life With KNB-63L: 9 hours - 5-5-90 duty cycle, with battery saver disabled
Battery voltage 7.5 V DC ± 20%
Frequency Tolerance ± 2,5 ppm (-20 ° C to + 60 ° C)
Operating temperature -20 ° C to + 60 ° C
PLL Increments per Channel 5.0 kHz / 6.25 kHz
Dimensions Radio with KNB-63L: W x H x D - 54 x 113 x 24.9 mm Projections not included
Weight (net) Radio only: 130 g With KNB-63L: 203 g

Receiver specifications

Adjacent channel selectivity 70dB at 25 kHz 70dB at 20 kHz 60dB at 12.5 kHz
Audio output power 500 mW
Intermodulation 65dB
Sensitivity - EIA 12 dB SINAD 0.28 µV at 25 kHz 0.28 µV at 20 kHz 0.35 µV at 12.5 kHz
Sensitivity - EN 20 dB SINAD 0.35 µV at 25 kHz 0.35 µV at 20 kHz 0.45 µV at 12.5 kHz
Spurious response rejection 70 dB

Transmitter specifications

RF output power (High / Low) 4 W / 1 W
FM noise (EIA) 45 dB at 25 kHz 45 dB at 25 kHz 40 dB at 12.5 kHz
Microphone impedance 1800 Ohm
Modulation distortion Less than 5%
Spurious emission (EN) -36 dBm ≤ 1 GHz -30 dBm & gt; 1 GHz
019048192363

Data sheet

Potencia
5W
Banda
VHF
Canales
16 Canales

Specific References

New product

Download

Hoja de Datos - TK2000/TK3000

Download (873.34k)
